Versions
| Code | Description | Limit switch |
|---|---|---|
| 74080050 | three-phase 230V without control unit | Mechanical |
| 74080054 | three-phase 400V without control unit | Mechanical |
| 74080250 | three-phase 230V without control unit | Electronic |
| 74080254 | three-phase 400V without control unit | Electronic |
Features
Adjustable speeds up to 2 m/s
Emergency operation always-engaged with crank or chain
Drastically reduced side installation dimensions to 10 cm with easy maintenance
For high-speed and fold-up doors up to 200 kg
Mechanical and electronic limit switch
Automatic and deadman control, with dry contact switches, integrated in the board
Technical data
Emergency operation with hand crank
Emergency operation with hand chain
Mechanical limit switch with safety microswitches
Electronic limit switch with absolute multi-turn encoder
| Power supply |
1~230 V
3~400 V
|
| Output torque on motor | 70 Nm |
| Output torque on shaft | 70 Nm |
| Max lift capacity | 200 Kg |
| Frequency | 50/60 Hz |
| Consumption |
7,2 A
4,3 A
|
| Power | 1700 W |
| Protection Category | IP 54 |
| Output speed on motor | 95 RPM |
| Output speed on shaft | 181 RPM |
| Ø Installation shaft | 25 / 25,4 (1”) / 30 mm |
