Versions
| Code | Description | Limit switch |
|---|---|---|
| 74930000 | three-phase 230V without control unit | Mechanical |
| 74930001 | three-phase 400V without control unit | Mechanical |
| 74940000 | three-phase 230V without control unit | Electronic |
| 74940001 | three-phase 400V without control unit | Electronic |
Features
Adjustable speeds up to 1,5 m/s
Emergency operation with hand crank
Traditional installation with side mounting using worm gear reducer
For high-speed and fold-up doors up to 186 kg
Mechanical and electronic limit switch
Automatic and deadman control, with dry contact switches, integrated in the board
Technical data
Emergency operation with hand crank
Electronic limit switch with absolute multi-turn encoder
Mechanical limit switch with safety microswitches
Electronic limit switch with KOSTAL
| Power supply |
1~230 V
3~400 V
|
| Output torque on motor | 2,85 Nm |
| Output torque on shaft | 65 Nm |
| Max lift capacity | 186 Kg |
| Frequency | 50/60 Hz |
| Consumption |
7,2 A
4,3 A
|
| Power | 1700 W |
| Protection Category | IP 54 |
| Output speed on motor | 93 RPM |
| Output speed on shaft | 177 RPM |
| Ø Installation shaft | 25 mm |
